Honeywell Residential HR90 Therapro Digital Programmable Radiator Thermostat With Backlight Freeze Protection & Safety Lock F/V
$109.10
The HONEYWELL RESIDENTIAL HR90 Therapro digital programmable radiator thermostat features a backlight, freeze protection, and a safety lock. It offers precise temperature control and energy efficiency. The digital display and user-friendly interface make programming and adjustments easy.
Description
Product Description
The HONEYWELL RESIDENTIAL HR90 Therapro digital programmable radiator thermostat features a backlight, freeze protection, and a safety lock. It offers precise temperature control and energy efficiency. The digital display and user-friendly interface make programming and adjustments easy. Compatible with most V2040 and Danfoss RA2000 valves.
- Digital programmable settings for customized heating schedules
- Backlight for convenient viewing in low light conditions
- Freeze protection to prevent freezing of pipes and equipment
Product Highlights
The HR90 thermostat ensures a comfortable and energy-efficient environment. It features an adjustable backlit display, operation/child lock, and auto frost protection.
Product Information
Standard Information
- Brand: HONEYWELL RESIDENTIAL
- Manufacturer Part Number: HR90
Technical Specifications
- Item Number: HR90
- Brand: HONEYWELL RESIDENTIAL
- Application: Radiator Control
- Power Method: Battery
- Temperature Range (F): 32°F to 122°F
- Display Type: LCD or LED
- Display Size: 30 x 26 mm
- Body-Head Connection: M30 x 1,5
- Approvals and Standards: CE Conform, RoHS
- Sensor Location: Integral
- Temperature Setting Range: 5 … 30 °C
- Frost Protection Temperature: 5 °C
- Control Temperature (Max): 122 ºF, 50 ºC
- Control Temperature (Min): 32 ºF, 0 ºC
- Ambient Operating Temperature (Max): 50 °C
- Ambient Operating Temperature (Min): 0 °C
- Operating Relative Humidity (Max): 90% RH
- Operating Relative Humidity (Min): 10% RH
- Element Type: NTC
- Number of Batteries: 2
- Battery Size: AA
- Battery Type: Lithium
- Battery Voltage: 1.5 Vdc
- Protection Class: IP 30
- Shipping and Storage Temperature (Max): 55 °C
- Shipping and Storage Temperature (Min): -20 °C
- Compatible With: Hot Water, Common thermostatic valves with a M30x1.5 connection without draining system, Danfoss RA2000 Valve Bodies
- Hazmat Information: NOT RESTRICTED – SPECIAL PROVISION A123
- Model Name: TheraPro
- Special Feature: Auto Changeover
- Specific Uses For Product: Radiator Heating
- Temperature Control Type: Heating
- Included Components: Thermostat, Mounting Bracket, Display Adjustment Component
- Power Source: Battery Powered
- Shape: Rectangular
- Finish Type: Glossy
- Control Type: Button Control
- Control Method: Push Button
- Mounting Type: Surface Mount
- Style: Modern
- Backlight: Yes
- Product Dimensions: 6.2 x 5.1 x 3.5 inches
- Item model number: HR90
- Batteries: 2 A batteries required. (included)
- Heating method: Radiant
- Finish types: Glossy
- Batteries required: Yes
Additional information
| Weight | 1.00 lbs |
|---|---|
| Brand | HONEYWELL RESIDENTIAL |
